![Hikoki CM 75EBP [13/220] English](/views2/1471572/page13/bgd.png)
English
13
Maintenance schedule
Daily maintenance
○ Clean the exterior of the machine.
○
Check that the nut on the arm cover is suffi ciently tightened.
○
Check that the bolts for the cut-off wheel are suffi ciently
tightened.
○
Check that the cut-off wheel does not rotate when the
engine is idling
○ Clean the air fi lter.
Weekly maintenance
○ Check the recoil starter, especially rope.
○ Clean the exterior of the spark plug.
○ Remove the spark plug and check the electrode gap.
Adjust it to 0.6 mm or change the spark plug.
○
Check that the air intake at the recoil starter is not clogged.
TROUBLESHOOTING
Condition Probable Cause Remedy
Engine does not start
No fuel or low fuel Supply fuel
Fuel is not in the carburetor
Supply fuel and push priming pump a
few times.
Old fuel Supply new fuel
Spark plug is wet
1. Remove spark plug and dry it
2. Pull starter and dry the fuel inside
the engine
The fuel pipe is bent or detached
Consult a HiKOKI Authorized Service
Center
Carburetor failure
Consult a HiKOKI Authorized Service
Center
Spark plug failure Replace spark plug or correct the gap
Electrical system failure
Consult a HiKOKI Authorized Service
Center
Engine starts but immediately stalls
No fuel or low fuel Supply fuel
Fuel is not in the carburetor
Supply fuel and push priming pump a
few times.
The choke is closed Push choke lever securely
Carburetor failure
Consult a HiKOKI Authorized Service
Center
Spark plug failure Replace spark plug or correct the gap
Clogged air fi lter Clean the air fi lter
Abnormal vibration
Faulty mounting of the cut-off wheel
Please refer to “Assembly of cut-off
wheel”
Deformation of the cut-off wheel Replace the cut-off wheel
Anti-vibration system failure
Consult a HiKOKI Authorized Service
Center
Engine starts, but the cut-off wheel
does not rotate
Belt is loose
Please refer to “Adjustment of belt”
Belt is too tight
Belt is out of pulleys Please refer to “Replacing of belt”
Engine does not stop Electrical system failure
Consult a HiKOKI Authorized Service
Center
Monthly maintenance
○ Rinse the fuel tank with gasoline, and clean fuel fi lter.
○ Clean the exterior of the carburetor and the space
around it.
Quarterly maintenance
○ Clean the cooling fi ns on the cylinder.
○ Clean the fan and the space around it.
○ Clean the carbon of muffl er.
CAUTION
Cleaning of cylinder fi ns, fan and muffl er shall be done
by HiKOKI Authorized Service Centers.
0000Book_CM75EAP.indb 130000Book_CM75EAP.indb 13 2018/06/05 14:22:102018/06/05 14:22:10
