Hikoki CM 75EBP [8/220] English

English

Q: Anti-vibration spring: Reduce the transmission of

vibrations to the operator’s hands.

R: Handle(W): Handle for rotating the wheel guard.

S: Decompression valve: Device for reducing the

compression pressure of engine to aid starting.

T: Tensioner bolt: Device to increase and release belt

tension.

U: Tension nut: Mark for indicating the state of tension of

the belt.

V: Cut-oﬀ wheel: Bonded abrasive with reinforced resinoid

wheel for cutting, with blotter.

W: Coupler: Device for attaching the hose

X: Valve: Device for adjusting water ﬂ ow rate.

Y: Muﬄ er: Reduces engine exhaust noise and directs the

exhaust gases.

Z: Wheel washer: Flange provided to clamp and drive the

cut-oﬀ wheel.

a: Bolt: Secures the cut-oﬀ wheel

b: Adapter collar: Spindle attachment for using arbor hole

25.4mm cut-oﬀ wheels.

c: Combi box spanner: Maintenance tool for removing or

installing a spark plug

d: Hex. wrench: Maintenance tool for removing cover and

tensioning the belt.

e: Protective glasses: Eye protection.

f: Handling instructions: Included with unit. Read before

operation and keep for future reference to learn proper,

safe techniques.

WARNINGS AND SAFETY

INSTRUCTIONS

Operator safety

○ Always wear a proper face shield or protective glasses.

○ Gloves should always be worn when operating this

machine and also when touching the cut-oﬀ wheel.

○ When using this machine, always wear proper protective

attire such as jacket, trousers, helmet, boots with steel

toe-caps and non-slip soles, and eye, ear, leg protection

equipment whenever you use this machine.

Do not wear loose clothing, jewelry, short pants and/or

sandals, or go barefoot.

○ Never let a child or inexperienced person operate the

machine.

A ﬁ rst-time operator should obtain practical instruction

before using the machine.

○ When you wear hearing protection, pay attention to your

surroundings. Be aware of any bystanders who may be

signaling a problem.

○ Cutting operations can expose you to respiratory

hazards such as silica and other harmful dust particles.

Please wear a protective mask when operating this

machine.

○ Keep handles free of oil and fuel.

○ Keep hands away from cutting equipment.

○ Do not grab or hold the machine by the cutting

equipment.

○ Do not smoke or allow smoking near fuel or the machine,

or while using the machine.

○ When the unit is shut oﬀ , make sure the cutting

attachment has stopped before setting down the unit.

○ When operation is prolonged, take a break periodically

so that you may avoid possible Hand-Arm Vibration

Syndrome (HAVS) which is caused by vibration.

○ National regulation can restrict the use of machine.

And the operator must obey the local regulations of

working area.

WARNING

○ The machine produces exhaust fumes, which include

hydrocarbons and benzene. When using this machine,

suﬃ cient ventilation is needed, not only if used indoors

but also when working in trenches, hollows or other

conﬁ ned locations. Breathing exhaust fumes can be

fatal.

○ Do not operate this machine when you are tired, ill or

under the inﬂ uence of alcohol, drugs or medication.

○ Antivibration systems do not guarantee that you will not

sustain Hand-Arm Vibration Syndrome or carpal tunnel

syndrome.

Therefore, continual end regular users should monitor

closely the condition of their hands and ﬁ ngers. If any

of the above symptoms appear, seek medical advice

immediately.

○ Long or continuous exposure to high noise levels may

cause permanent hearing impairment. Always wear

approved hearing protection when operating a machine.

○ If you are using any medical electric/electronic devices

such as a pacemaker, consult your physician as well as

the device manufacturer prior to operating any power

equipment.

Unit / machine safety

○ Inspect the entire machine for any damage before each

use. Check for fuel leaks and make sure all fasteners are

in place and securely tightened.

○ Keep others away when making carburetor adjustments.

○ Use only accessories as recommended for this machine

by the manufacturer.

○ Select and mount the correct cut-oﬀ wheel for the type of

work to be carried out.

○ All items, other than the items listed in the operator’s/

owner’s manual, should be performed by HiKOKI

Authorized Service Centers. (For example, if improper

tools are used to remove the ﬂ ywheel or if an improper

tool is used to hold the ﬂ ywheel in order to remove the

clutch, structural damage to the ﬂ ywheel could occur

and could subsequently cause the ﬂ ywheel to burst.)

WARNING

○ Never modify the machine in any way. Do not use your

machine for any job except that for which it is intended.

○ Never use wheels that are rated for speeds lower than

the maximum spindle speed indicated on the machine.

A wheel running faster than its rated speed can break

and ﬂ y apart.

○ The arbor size of wheels and ﬂ anges must properly ﬁ t

the spindle of the machine.

Wheels and ﬂ anges with arbor holes that do not match

the mounting hardware of the machine will run oﬀ -

balance, vibrate excessively and may cause loss of

control.

○ It is important to use only cut-oﬀ wheels designed for use

on hand-held cut-oﬀ machines. It is dangerous to use a

cut-oﬀ wheel that is not intended for a hand-held cut-oﬀ

machine.

Fuel safety

○ Mix and pour fuel outdoors and where there are no

sparks or ﬂ ames.

○ Use a container approved for fuel.

○ Wipe oﬀ all fuel spills and allow any remaining fuel to

evaporate before starting engine.

○ Move at least 3 m away from fueling site before starting

engine.

○ Stop engine and let it cool for a few minutes before

opening fuel tank cap.

○ Store the machine and fuel in area where fuel vapors

cannot reach sparks or open ﬂ ames from water heaters,

electric motors or switches, furnaces, etc.

0000Book_CM75EAP.indb 80000Book_CM75EAP.indb 8 2018/06/05 14:22:102018/06/05 14:22:10
