Port Voice
VLAN Mode
Voice
Stream Type
Link type of the port and processing mode
Manual Mode
TAG voice
stream
Untagged: Not supported.
Tagged：
Supported. The default VLAN of the port should not
be voice VLAN.
UNTAG voice
stream
Untagged: Supported.
Tagged: Not supported.
Table 10-2 Port voice VLAN mode and voice stream processing mode
Security Mode of Voice VLAN
When voice VLAN is enabled for a port, you can configure its security mode to filter data stream. If
security mode is enabled, the port just forwards voice packets, and discards other packets whose
source MAC addresses do not match OUI addresses. If security mode is not enabled, the port
forwards all the packets.
Security Mode
Packet Type Processing Mode
Enable
UNTAG packet
When the source MAC address of the packet is the OUI
address that can be identified, the packet can b
e
transmitted in the voice VLAN. Otherwise, the packet will
be discarded.
Packet with voice
VLAN TAG
Packet with other
VLAN TAG
The processing mode for the device to deal with the packet
is determined by whether the port permits the VLAN or not,
independent of voice VLAN security mode.
Disable
UNTAG packet
Do not check the source MAC address of the packet and all
the packets can be transmitted in the voice VLAN.
Packet with voice
VLAN TAG
Packet with other
VLAN TAG
The processing mode for
the device to deal with the packet
is determined by whether the port permits the VLAN or
not, independent of voice VLAN security mode.
Table 10-3 Security mode and packets processing mode
Note:
Don’t transmit voice stream together with other business packets in the voice VLAN except for
some special requirements.
The Voice VLAN function can be implemented on Global Config, Port Config and OUI Config
pages.
10.3.1 Global Config
On this page, you can configure the global parameters of the voice VLAN, including VLAN ID and
aging time.
169
