WRE6602 User’s Guide
2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Screenshots and graphics in this book may differ slightly from what you see due to differences in release
versions or your computer operating system. Every effort has been made to ensure that the information
in this manual is accurate.
Related Documentation
•Quick Start Guide
The Quick Start Guide shows how to connect the managed device.
•Easy Link App
The Easy Link app helps you install the WRE6602, configure its settings and check signal strength.
•More Information
Go to support.zyxel.com to find other information on the WRE6602
.
