8
Caution! Before you begin cleaning you
should test the materials to be clea ned
as to their suitability for cleaning with
steam. Do not hold the steam nozzle for
too long and too close in one position.
Overview of the Controls
1 On/off switch
2 Kettle/water tank
3 Hose with connecting head
4 Safety lock/Filling aperture
5 Steam switch on the connecting head
6 Carrying handle
7 Connection cable
8 Funnel
9 Measuring beaker
10 2 extension tubes
11 Jet nozzle with round brush attachment
12 Floor brush nozzle
13 Window wiper
14 Non-woven cover
Initial Operation
Filling up the Heating Boiler before Use!
Before the tank lock is opened
the power plug must be removed
from the socket. Please make sure
the device is depressurized by
pressing the steam switch.
Caution! Before unscrewing the
lock (4) proceed as follows:
• Remove the power plug from the socket.
• Release the pressure by using
the steam switch (5).
• If the device is still warm, please wait 5
minutes before removing the seal completely.
Press the seal downwards and turn.
Caution! Danger of Injury!
Please open the safety lock (4) only when
no more steam comes out of the nozzle.
Shake any residual water out of the kettle
(2). Then fill the measuring beaker (9) and
pour the water into the kettle. Use a funnel
(8) if necessary. Re-fasten the safety lock (4).
Attachment of the
Individual Accessories
It is possible to attach the individual nozzles
directly to the connecting head of the hose (3):
• Attach one of the nozzles to the connecting
head of the hose until it locks in place.
• In order to release the nozzle again please press
the button on the connecting head of the hose.
• Keep the button pressed down
and then pull the nozzle off
or extend the nozzle attachments with
one or two extension tubes (10).
• Insert one extension tube into the other
until it locks in place and then insert the
connected tubes into the handle section (3).
• Then attach the floor brush nozzle
(12) or the accessories.
• In order to release the extension tube, please
press the button on the connec ting head.
Jet nozzle with round brush attachment (11):
For cleaning joints, the edges of bath tubs or
areas which are difficult to access etc.
Floor brush nozzle (12):
For large surfaces, such as laminate or tiles etc.
Window wiper (13):
For window cleaning, shower partitions etc.
Non-woven cover (14):
Non-woven cover for sensitive surfaces. Please
use the cover together with the window wiper.
Switching on the Device
• Before inserting the mains lead into the
socket, check whether the voltage you intend
to use complies with that of the machine.
For details see the machine label.
• Only connect the machine to a properly
installed safety socket, 230 V/50 Hz.
• Turn the on/off switch (1) on top of the device to “I”.
• After about 3-4 minutes the pressure in
the boiler has built up. Please press the
steam switch (5) to produce steam.
