12
TASCAM SS-CDR250N / SS-R250N
1 – Introduction
Slot loading of discs
1. As shown in the illustration, hold the disc with the labeled
side up and insert it part way into the slot.
2. Push the disc in a little further and it will be pulled in auto-
matically just before it disappears into the slot.
Trouble inserting a disc
If the disc becomes stuck during insertion, for example, and is
difficult to push, do not try to force the disc in. Pull the disc out
once and press the EJECT button and then try inserting it again.
(Trying to force the disc in could damage the unit.)
Using the TEAC Global Site
You can download updates for this unit from the TEAC Global
Site:
http://teac-global.com/
In the TASCAM Downloads section, select the desired language
to open the Downloads website page for that language.
Product registration
Customers in the USA, please visit the following TASCAM website
to register your TASCAM product online.
http://tascam.com/
About TASCAM customer support service
TASCAM products are supported and warrantied only in their
country/region of purchase.
To receive support after purchase, on the TASCAM Distributors list
page of the TEAC Global Site (http:// teac-global.com/), search
for the local company or representative for the region where you
purchased the product and contact that organization.
When making inquiries, the address (URL) of the shop or web
shop where it was purchased and the purchase date are required.
Moreover, the warranty card and proof of purchase might also
be necessary.
