TASCAM SS-CDR250N / SS-R250N
77
10 – CD functions (SS-CDR250N only)
6. Press the MULTI JOG dial to open the SELECT BURN SOURCE
screen for the selected medium.
7. After selecting all the folders and files to copy to the CD-R/
CD-RW disc, press the MULTI JOG dial to open the pop-up
file menu.
If you select a folder, all files inside the folder will be copied.
8. Select the SELECT/UNSELECT item in the file menu, and press
the MULTI JOG dial.
A check (4) is added to selected folders and files.
Multiple files and folders inside the same folder can be se-
lected.
To select multiple folders and files, repeat this procedure: se-
lect a desired folder or file, then select the SELECT/UNSELECT
item from the file menu and press the MULTI JOG dial.
To cancel selection of the selected folder or file, select the
SELECT/UNSELECT item from the file menu and press the
MULTI JOG dial.
NOTE
Since only folders and files inside the same folder can be se-
lected, you will not be able to move to another folder after
selecting the first folder or file.
9. After selecting all the files to copy to the CD-R/CD-RW disc,
press the MULTI JOG dial to open the pop-up file menu.
10. Select the NEXT STEP item in the file menu, and press the
MULTI JOG dial.
The SELECT BURN TARGET screen will open
If the open disc space or track number limit would be ex-
ceeded by the items selected to copy, you will not be able to
open the BURN TARGET SELECT screen. If this occurs, dese-
lect some of the selected folders and files so that the limits
are not exceeded.
NOTE
i
If the total size of the files to be copied exceeds the remain-
ing capacity of the selected medium or if the number of tracks
or folders exceed system limits, a corresponding “No Free
Space”, “ Track limit reached.” or “Folder limit reached.”
pop-up message will appear.
i
If this occurs, press the MENU [JOG] button to close the pop-
up message, and reduce the total copy source size or number
before selecting the NEXT STEP item.
11. Turn the MULTI JOG dial to select where you want to write
the data (the target).
If the disc already has a folder structure, move on the BROWSE
screen to where you want to write the content.
The folders and files will be written to the position indicated
by “BURN HERE”.
12. After selecting the write position, select the NEXT STEP item
in the file menu, and press the MULTI JOG dial.
A confirmation pop-up message will appear.
NOTE
If the same name already exists, a “Cannot BURN. This name
already exists.” pop-up message will appear.
13. Press the MULTI JOG dial to start writing the CD-R/CD-RW
disc.
When track writing completes, the CD menu will reopen.
NOTE
When you press the EJECT button to eject the CD-R/CD-RW
disc, the disc will automatically be finalized before being
ejected. (See “Finalizing CD-R/CD-RW discs” on page 73.)
