94
TASCAM SS-CDR250N / SS-R250N
13 – Network Functions
Setting the SNTP function
Use the SNTP page to make settings for automatically synchroniz-
ing with the date and time of an Internet time server.
SNTP STATUS
This shows the current status of the SNTP function.
Message Status
SUCCESSFUL UPDATE
The time was updated properly.
SUCCESS UPDATE (SKEW)
A delay occurred, but the time was
updated.
STARTING UP
The unit is preparing for operation.
ACCESSING SERVER
The unit is connecting with a server.
DISABLED
The SNTP function is disabled.
WAITING FOR NETWORK
The unit is waiting to confirm the
network connection.
SERVER NAME NOT FOUND
The server name could not be found
on the DNS server.
SERVER NAME FOUND
The server name was found on the
DNS server.
SERVER CONNECT FAILED
The server has not responded.
REFUSING CONNECTIONS
Server responded, but is refusing
additional connections; select a
different SNTP server.
SNTP UPDATE
This shows the setting status of the MODE item on the SNTP UP-
DATE screen.
Select SNTP UPDATE, and open the SNTP UPDATE screen. (See
“Menu operation procedures” on page 22.)
MODE item:
Set the SNTP function update mode.
Option Meaning
DISABLE (default)
Do not use an SNTP function update
mode.
START UP
When the unit starts up, get the time
from an NTP server and use it to set
the built-in clock.
START UP/24CYCLE
Get the time from an NTP server and
use it to set the built-in clock when
the unit starts up, as well as when
the time set with the TIME item
occurs every 24 hours.
TIME item:
Set the time to acquire the time from the NTP server.
Options: 00:00 - 00:09 – 23:00 - 23:09 (01:00 steps)
(default: 00:00 - 00:09)
NOTE
i
When using the SNTP function, you must set the NETWORK 1
page DNS SETUP item and the NTP Server item, which is ex-
plained below.
i
On this screen, local time is set, not Coordinated Universal
Time (UTC).
i
Since access to SNTP servers on the hour could result in con-
gestion, the unit will access the SNTP server randomly during
the first 10 minutes of the hour.
NTP SERVER
This shows the setting status of the NTP SERVER screen.
Select NTP SERVER, and open the NTP SERVER screen. (See “Menu
operation procedures” on page 22.)
Edit the NTP server name, which must have no more than 32
characters (default: ntp.nict.jp).
For details about how to edit the text, see “Editing text” on page
64.
NOTE
Press the MULTI JOG dial on PRESET
5
to open a pull up
menu.
Turn the MULTI JOG dial to select a menu item, and press the
MULTI JOG dial to input the preset value of that item.
Press the MENU [JOG] button to close the pull-up menu.
