![Tascam SS-R250N [32/112] Setting the play mode](/views2/1553299/page32/bg20.png)
32
TASCAM SS-CDR250N / SS-R250N
4 – Playback
Setting the play mode
The mode used to play tracks in the playback area can be set.
1. Select PLAY MODE on the PLAY 1 page to open the MODE AREA
screen. (See “Menu operation procedures” on page 22.)
2. Set the desired play mode.
Option Meaning
CONTINUE
(default)
Play tracks in the playback area in track num-
ber order.
SINGLE
Play the selected track, and stop after playback.
PROGRAM
Play in program order set in advance. (See
“Program playback” on page 33.)
RANDOM
Play all tracks in the playback area in random
order regardless of track number.
Stop playback after all tracks have been played.
3. Confirm the setting and return to the Menu Screen.
NOTE
i
Unless otherwise specified, explanations in this manual as-
sume that the playback mode is set to CONTINUE.
i
The current playback mode appears in the lower right of the
Home Screen.
Basic playback operations
This section explains basic playback operations, including start-
ing, stopping and pausing.
This explanation assumes that you have already made necessary
connections, turned the unit on, loaded a card or drive that con-
tains audio files, selected the current medium, and opened the
Home Screen on the display.
Playing tracks
Press the PLAY button on the unit or the remote control to start
playback.
If the medium does not contain any audio files that the unit can
play, the Home Screen will appear as shown below.
Stopping playback:
Press the STOP button.
Pausing playback:
Press the PAUSE [CALL] button.
Selecting tracks for playback
This section explains how to select a track when there are mul-
tiple tracks available for playback. The two ways to select tracks
are moving (skipping) backward/forward by track number and
specifying track numbers directly.
Skipping to earlier and later tracks
Turn the MULTI JOG dial (or use the remote control
m
[
.
]
and
,
[
/
] buttons) to skip to earlier and later tracks.
0 During track playback, turn the MULTI JOG dial counterclock-
wise (or press the remote control
m
[
.
] button) to return
to the track beginning. When already at the beginning of a
track, turn the MULTI JOG dial counterclockwise (or press the
remote control
m
[
.
] button) to skip to the beginning of
the previous track.
0 When at the beginning or middle of a track, turn the MULTI
JOG dial clockwise (or press the remote control
,
[
/
]
button) to skip to the beginning of the next track.
After selecting a track, press the PLAY button (or remote control
PLAY button) to start playing it back. Press the PAUSE [CALL]
button to pause playback at the beginning of the selected track.
NOTE
i
Only tracks in the current playback area can be played back.
i
The track number, file name and other file information for the
currently playing file appear on the display.
i
Turn the MULTI JOG dial as necessary to move between tracks.
Selecting tracks directly
On the BROWSE screen, turn the MULTI JOG dial (or use the re-
mote control
m
[
.
] and
,
[
/
] buttons) to select the
track you want to play, and press the PLAY button (or remote
control PLAY button) to start playback.
