18
TASCAM SS-CDR250N / SS-R250N
2 – Names and Functions of Parts
This shows the name of the currently selected medium. (See
“Selecting media” on page 29.)
: USB flash drive selected
: SD card 1 selected
: SD card 2 selected
: CD selected
5 Display mode
This shows the current Home Screen display mode.
6 Track number
This shows the number of the currently playing track.
7 Mark display
Marks are shown by
b
icons.
8 Track playback position
This bar shows the current playback position.
As playback progresses, the bar extends from the left.
9 Playback function activation status
Icons appear for the playback functions that are currently on.
Icon Meaning
Appears when auto ready function is on
Appears when auto cue function is on
Appears when incremental playback function
is on
Appears when already flash loaded
0 Pitch control status
This shows whether the pitch control function is on/off and
the currently set pitch adjustment.
q Key control status
This shows whether the key control function is on/off and the
currently set key adjustment.
w Repeat playback status
An icon appears when the repeat playback function is on.
: Repeat playback
: A-B repeat playback
e Upload/download status
An icon appears when files, for example, are being uploaded
or downloaded via a network.
: Uploading
: Downloading
r Track title
This shows the title of the current track.
Press the SHIFT button on the unit to scroll this.
t Playback mode
This shows the current playback mode. (See “Setting the play
mode” on page 32.)
: Continuous playback mode
: Single playback mode
: Program playback mode
: Random playback mode
y Timer event setting status
The icon appears when the timer event function is on. (See
“Turning the timer event function on/off” on page 81.)
u Playback area
This shows the current playback file area.
: All files on the current medium
: All files in the selected folder
: All files assigned to the playlist
i Total track recorded time
This shows the elapsed time of the play area (hours: minutes:
seconds).
o Total track remaining time
This shows the remaining time of the play area (hours: min-
utes: seconds).
p Total elapsed playback position
This bar shows the current playback position.
As playback progresses, the bar extends from the left.
a Track number/total number of tracks
This shows the current track number and total number of
tracks in the current playback area.
s Folder name
This shows the name of the folder that contains the current
track.
NOTE
i
When stopped, the total playback time of the playback area
is always shown regardless of the Home Screen display mode
setting.
i
In PROGRAM mode, the elapsed time and remaining time are
shown for the entire program rather than the entire playback
area.
