TASCAM SS-CDR250N / SS-R250N
29
3 – Preparation
Selecting media
Before conducting other operations, select the medium to use
(USB, SD1, SD2 or CD).
Follow the procedures below to select the medium.
1. Press the MEDIA button to open the MEDIA SELECT screen.
2. Press the MEDIA button to select the medium to use, and
press the MULTI JOG dial to confirm it.
3. The name of the currently selected medium appears in the
current medium area of the Home Screen.
Current media name
Icon Meaning
: USB flash drive selected
: SD card 1 selected
: SD card 2 selected
No media loaded or media invalid
Finalized CD* (with TOC data)
Finalized CD-R
Unfinalized CD-R
Finalized CD-RW
Unfinalized CD-RW
* This will also be used with commercial audio CDs.
Preparing SD cards and USB flash
drives for use
In order to use an SD card or USB flash drive with this unit, you
must use this unit to format it first.
CAUTION
i
Formatting erases all the data on the SD card or USB flash
drive.
i
Always use this unit to format media to be used with it. Op-
eration of this unit might be affected when using an SD card
or USB flash drive that has been formatted by a computer or
other device.
i
This cannot be selected when the current medium is CD.
1. Open the MEDIA SELECT screen, and select the medium to
format. (See “Selecting media” on page 29.)
2. Select the MEDIA FORMAT item on the MEDIA page to open a
format method option pop-up. (See “Menu operation proce-
dures” on page 22.)
QUICK FORMAT: Format only system data on the medium.
FULL FORMAT: Completely format the medium.
NOTE
The ERASE FORMAT item only appears when the current medi-
um is SD1 or SD2.
3. Select the format method, and press the MULTI JOG dial.
A confirmation pop-up message will appear.
NOTE
Press the MENU [JOG] button to cancel formatting.
4. Press and hold the MULTI JOG dial to start formatting.
The following pop-up message will appear during format-
ting.
When QUICK FORMAT selected
5. When formatting completes, the pop-up disappears and the
Home Screen opens.
NOTE
The writing speeds to SD cards and other storage media that
use flash memory tend to decrease after writing occurs re-
peatedly.
If the writing speed decreases, this could have a negative im-
pact on recording.
Using the ERASE FORMAT function of this unit should restore
the writing speed of an SD card.*
For this reason, we recommend using the ERASE FORMAT func-
tion at the following times.
o Whenever the card has been written to until it became
completely full
o On a regular schedule (about once per month)
o Before starting important recordings
* Writing speed might not be restored depending on the SD
card condition (including malfunction and age).
