20
TASCAM SS-CDR250N / SS-R250N
2 – Names and Functions of Parts
t Total track elapsed time
This shows the total recording time of everything on the cur-
rent medium (hours: minutes: seconds).
y Total track remaining time
This shows the remaining recording time available on the cur-
rent medium (hours: minutes: seconds).
u Total recording position
The current recording position is shown by a bar.
As recording progresses, the bar extends from the left.
i Track number/total number of tracks
This shows the current track number and total number of
track in the current playback area.
o Name of track recording folder
This shows the name of the folder where tracks are recorded.
NOTE
The remaining time differs according to the file recording for-
mat. (See “Setting the recording file format” on page 61.)
Menu structure
Press the MENU [JOG] button to open the PLAY 1 page of the
menu.
The SS-CDR250N MENU screen has 22 pages and the SS-CDR250N
MENU screen has 21 pages organized by types of menu items.
Page name Contents
1
PLAY 1
Make playback settings.
2
PLAY 2
3
PLAY 3
4
PLAYLIST
Make playlist settings.
5
REC 1
Make recording settings.
6
REC 2
7
REC 3
8
REC 4
9
REC 5
10
CD
This menu includes CD-specific operations.
(SS-CDR250N only)
11
TIMER EVENT
Make timer event settings.
12
MARK LIST
Make mark list settings.
13
NETWORK 1
Make network settings.
14
NETWORK 2
15
FTP CLIENT
Make FTP settings.
16
SNTP
Make SNTP settings.
17
UTILITY
Make utility settings.
18
PREFERENCES
Make preference settings.
19
REMOTE
Make remote control settings.
20
MEDIA
Work with media.
21
SYSTEM 1
Make system settings.
22
SYSTEM 2
The various menu items are as follows.
Menu item Function Page
PLAY 1 page
PLAY AREA
Playback area setting page 31
PLAY MODE
Playback mode setting page 32
REPEAT
Repeat playback function
settings
page 35
AUTO CUE
Auto cue function settings page 35
AUTO READY
Auto ready function
setting
page 36
PLAY 2 page
INCREMENTAL PLAY
Incremental playback
function setting
page 36
MONO MIX
Mono playback function
setting
page 36
DUCKING
Ducking function settings page 37
EOM TRACK
EOM function settings page 37
EOM MEDIA
PLAY 3 page
RESUME
Resume playback function
setting
page 38
TIME SKIP
Time skip function setting page 38
FADER DELAY
Playback start timing
setting
page 39
OUTPUT RATE
Audio output setting for
external sampling fre-
quency synchronization
page 39
CALL
Call function setting page 39
PLAYLIST page
PLAYLIST EDIT
Playlist editing page 50
REC 1 page
INPUT SELECT
Input source selection page 56
REC SET LINK
Input channel link setting
page 57
BAL. INPUT GAIN
Mic input sensitivity
setting
page 58
INPUT LEVEL
Input volume setting page 58
MIC PHANTOM
Phantom power setting page 59
REC 2 page
MIC AGC
Automatic gain control for
mic input function setting
page 59
DYNAMICS
Dynamics function setting page 60
LOW CUT
Low-cut filter setting
page 60
REC 3 page
REC FORMAT
Recording file format
setting
page 61
BACKUP/RELAY MEDIA
Backup and relay record-
ing media settings
page 62
WAV SETTING
WAV file settings page 62
MP3 BITRATE
MP3 file bit rate setting
page 62
STEREO/MONO
Recording input channel
setting
page 62
REC 4 page
FILE NAME
Set the file name format page 63
DITHER
Dither setting page 64
SRC
Sampling rate converter
setting
page 64
