TASCAM SS-CDR250N / SS-R250N
21
2 – Names and Functions of Parts
Menu item Function Page
PAUSE MODE
Pause mode function
setting
page 65
DIRECT REC
Direct record function
setting
page 65
REC 5 page
PRE REC
Pre-recording function
setting
page 65
SYNC REC
Synchronized recording
settings
page 65
AUTO TRACK
Automatic track incremen-
tation function settings
page 67
AUTO MARK
Automatic mark function
settings
page 68
CD page (SS-CDR250N only)
FINALIZE
Finalize unfinalized CD-R/
CD-RW discs
page 73
ERASE
Erase a written CD-RW disc page 73
BURN TO CD
Write from the selected
media to a CD-R/CD-RW
disc
page 75
RIP TO MEMORY
Write from a CD to the
selected media
page 78
TIMER EVENT page
TIMER EVENT
Timer event function
setting
page 81
TIMER EVENT LIST
Timer event list screen
settings
page 81
MARK LIST page
MARK LIST
Mark list editing page 87
NETWORK 1 page
MAC ADDRESS
View the unit's MAC
address
page 90
IP ADDRESS
View the current IP ad-
dress
DNS ADDRESS
View the IP address of the
DNS server
IP SETUP
Set the unit's IP address
and related settings
page 90
DNS SETUP
Set the IP address of the
DNS server
NETWORK 2 page
IP PASSWORD
Password setting page 91
NICKNAME
Nickname setting page 91
ADMIN PASSWORD
Admin Password setting page 91
FTP CLIENT page
TARGET FTP SERV-
ER
Various settings for FTP
server connections
page 91
FTPS MODE
FTP mode setting
TARGET FOLDER NAME
Set default folder for FTP
server uploads and down-
loads
ACCESS TEST
Test connection with FTP
server
AUTO UPLOAD
Automatic uploading to
FTP server setting
Menu item Function Page
SNTP page
SNTP STATUS
View the current SNTP
status
page 94
SNTP UPDATE
Set the SNTP function
update mode
NTP SERVER
NTP server name setting
page 94
TIMEZONE
Set the time offset from
Coordinated Universal
Time (UTC)
DAYLIGHT SAVING
Set the daylight savings
time function
UTILITY page
LINK PLAY
Link playback settings page 40
POWER ON ACTION
Power on action function
setting
page 96
OUTPUT LEVEL
Analog output attenuation
function setting
page 96
REMOTE POWER
CONTROL
Remote power control
function setting
page 96
PREFERENCES page
REFERENCE LEVEL
Reference level setting page 96
BRIGHTNESS
Display and indicator
brightness setting
page 26
LCD CONTRAST
Display contrast setting page 26
KEYBOARD
Keyboard type setting page 97
REMOTE page
RS-232C
RS-232C settings page 102
RC-3F
RC-3F mode setting page 102
RECORD TALLY
Record Tally setting page 102
MEDIA page
MEDIA FORMAT
Media formatting settings
page 29
MEDIA INFORMA-
TION
View media information page 99
SYSTEM 1 page
CLOCK ADJUST
Date and time settings page 26
FACTORY PRESET
Restore factory default
settings
page 99
SAVE USER PRESET
Write user settings page 99
LOAD USER PRESET
Load user settings page 99
SYSTEM BACKUP
Import/export system
backup data
page 100
SYSTEM 2 page
VERSION
View the firmware version page 101
UPDATE
Update the firmware page 101
NOTE
The settings for all menu items are retained even when the
unit is turned off.
