Multifunction Process Calibrator

Using Measure Mode

Table 6. RTD Types Accepted

RTD Type Ice Point (R

) Material α Range (°C)

Pt100 (3926) 100 Ω Platinum 0.003926 Ω/°C -200 to 630

Pt100 (385) 100 Ω Platinum 0.00385 Ω/°C -200 to 800

Ni120 (672) 120 Ω Nickel 0.00672 Ω/°C -80 to 260

Pt200 (385) 200 Ω Platinum 0.00385 Ω/°C -200 to 630

Pt500 (385) 500 Ω Platinum 0.00385 Ω/°C -200 to 630

Pt1000 (385) 1000 Ω Platinum 0.00385 Ω/°C -200 to 630

Pt100 (3916) 100 Ω Platinum 0.003916 Ω/°C -200 to 630

The IEC standard RTD commonly used in U.S. industrial applications is the Pt100 (385), α = 0.00385 Ω/°C.

Pt100 (3916), α = 0.003916 Ω/°C is also designated as JIS curve.

Custom RTDs may also be added, see PRT Custom Curves
