![Fluke 726 [52/80] Storing and recalling setups](/views2/1005547/page52/bg34.png)
726
Users Manual
42
Manually Stepping the mA Output
To manually step current output:
• Use
H or I to step the current up or down in
25 % steps.
• Touch either
J to go to 0 %, or G to go to
100 %.
Auto Ramping the Output
Auto ramping can continuously apply a varying stimulus
from the Calibrator to a transmitter, while your hands
remain free to test the response of the transmitter.
When
L is pressed, the Calibrator produces a
repeating 0 % - 100 % - 0 % ramp in a choice of three
ramp waveforms:
•
E 0 % - 100 % - 0 % 40-second smooth ramp
•
P 0 % - 100 % - 0 % 15-second smooth ramp
•
N 0 % - 100 % - 0 % Stair-step ramp in 25 %
steps, pausing 5 seconds at each step. Steps are
listed in Table 7.
To exit ramping, press any button.
Table 7. mA Step Values
Step 4 to 20 mA
0 % 4.000
25 % 8.000
50 % 12.000
75 % 16.000
100 % 20.000
Storing and Recalling Setups
Up to eight settings can be stored in a nonvolatile
memory to recall for later use. A low battery condition or
a battery change does not jeopardize the stored settings.
Store a Setup
To store a setup:
1. Create the desired setup.
2. Push S. The right side of the display changes to
show SAVE SETUP and SAVE DATA.
3. Push Sto select SAVE SETUP.
4. Push Y or Z to select the desired memory location (at
the top of the LCD).
5. Push S to enter the setup.
