726
Users Manual
54
Cleaning the Calibrator
WCaution
To avoid damaging the plastic lens and case,
do not use solvents or abrasive cleansers.
Clean the Calibrator and pressure modules with a soft
cloth dampened with water or water and mild soap.
Service Center Calibration or Repair
Calibration, repairs, or servicing not covered in this
manual should be performed only by qualified service
personnel. If the Calibrator fails, check the batteries first,
and replace them if needed.
To locate an authorized service center, refer to
“Contacting Fluke” at the beginning of the manual.
Replacement Parts
Table 8 lists the part number of each replaceable part.
Refer to Figure 25.
Table 8. Replacement Parts
Item Description PN Qty.
1 AA alkaline batteries 376756 4
2 Case screws 832246 4
3 Battery door 664250 1
4 Accessory mount 658424 1
5 Tilt stand 659026 1
6 Battery door 1/4-turn
fasteners
948609 2
7 TL75 series test leads
855742 1
8 Test lead, red
Test lead, black
688051
688066
1
1
9
726 Product Overview
Manual
2441588 1
10 AC72 alligator clip, red
AC72 alligator clip, black
1670641
1670652
1
1
11
725/726 CD ROM
,
contains User Manual
1549615 1
