726

Users Manual

Table 10. Pressure Modules (cont.)

Fluke Model Number Range Type and Media

Fluke-700P29 0 to 3,000 psi gage, wet

Fluke-700P30 0 to 5,000 psi gage, wet

Fluke-700P31 0 to 10,000 psi gage, wet

Fluke-700PA3 0 to 5 psi absolute, wet

Fluke-700PA4 0 to 15 psi absolute, wet

Fluke-700PA5 0 to 30 psi absolute, wet

Fluke-700PA6 0 to 100 psi absolute, wet

Fluke-700PV3 0 to -5 psi vacuum, dry

Fluke-700PV4 0 to -15 psi vacuum, dry

Fluke-700PD2 ±1 psi dual range, dry

Fluke-700PD3 ±5 psi dual range, dry

Fluke-700PD4 ±15 psi dual range, dry

Fluke-700PD5 −15/+30 psi dual range, wet

Fluke-700PD6 −15/+100 psi dual range, wet

Fluke-700PD7 −15/+200 psi dual range, wet
