Ordering
Take a copy of the ordering form, see section Ordering
form. Fill in and post or fax your order to the nearest
branch office of the Danfoss sales organisation. On the
basis of your order, the FCM 300 Series motor is given
a type code.
The ordering form for the basic unit must always be
completed. When the type code is written, always state
the characters of the basic string (1-34). Together with
the order confirmation the customer receives an 8-fig-
ure code number to be used when reordering.
Danfoss PC software for serial communication, MCT
10
All FCM 300 Series units have an RS 485 port as
standard, which enables them to communicate e.g.
with a PC. A programme entitled MCT 10 is available
for this purpose (see section PC Software tools).
Ordering numbers, MCT 10
Please order your CD containing MCT 10 Set-up Soft-
ware using code number 130B1000.
Accessories for the FC motor
A Local Operation Pad (LOP) for local set point and
start/stop is available for the FC motor. The LOP is IP
65 enclosed. A Local Control Panel (LCP 2) which
makes up a complete interface for operation, program-
ming and monitoring of the FC motor is also available.
Ordering numbers, accessories
Local Operation Pad incl. cable(LOP) 175N0128
Local Control Panel (LCP 2) 175N0131
Remote mounting kit (LCP 2) 175N0160
Plug kit (LCP 2) 175N2545
Cable for plug kit (LCP 2) 175N0162
Cable (direct mounting) (LCP 2) 175N0165
Service plug kit (LCP 2) 175N2546
Potentiometer option 177N0011
PC Software tools
PC Software - MCT 10
All drives are equipped with a serial communication
port. We provide a PC tool for communication between
PC and frequency converter, VLT Motion Control Tool
MCT 10 Set-up Software.
MCT 10 Set-up Software
MCT 10 has been designed as an easy to use inter-
active tool for setting parameters in our frequency
converters.
The MCT 10 Set-up Software will be useful for:
• Planning a communication network off-line.
MCT 10 contains a complete frequency con-
verter database
• Commissioning frequency converters on line
• Saving settings for all frequency converters
• Replacing a drive in a network
• Expanding an existing network
• Future developed drives will be supported
The MCT 10 Set-up Software Modules
The following modules are included in the software
package:
MCT 10 Set-up Software
Setting parameters
Copy to and from frequency converters
Documentation and print out of param-
eter settings incl. diagrams
SyncPos
Creating SyncPos programme
Ordering number:
Please order your CD containing MCT 10 Set-up Soft-
ware using code number 130B1000.
VLT
®
FCM Series
10 MG.03.H6.02 - VLT
®
is a registered Danfoss trademark
