All operations must be carried out by ap-
propriately trained personel.
Use all lifting facilities provided e.g. both
lifting points if fitted or single lifting point if
fitted*.
Vertical lifting - Prevent uncontrolled rota-
tion.
Lift machine - Do not lift other equipment
with motor lifting points only.
Before installation check for fan cover
damage, shaft damage, foot/mounting
damage, and loose fasteners. Check
nameplate details.
Ensure level mounting surface, balanced
mounting, not misaligned.
Gaskets, and/or sealants, and guards
must be correctly fitted.
Correct belt tension.
Please observe derating rules, see "Special condi-
tions".
*Note: maximum hand lift is 20 kg below shoulder, but
above ground level. Max. gross weights:
-
Frame size 80: 15 kg
-
Frame size 90 & 100: 30 kg
-
Frame size 112: 45 kg
-
Frame size 132: 80 kg
The voltage on the FC motor is dangerous
when the motor is connected to mains. In-
correct installation of the FC motor may
lead to material damage or serious injury,
or it may be fatal.
Consequently, the instructions in this
manual as well as national and local rules
and safety regulations must be complied
with.
Touching the electrical parts may be fatal,
even after the mains supply has been dis-
connected. Wait at least 4 minutes.
- Installation must be fused and isolated
correctly.
- Covers and cable entries must be fitted.
By altitudes above 2 km, please contact
Danfoss Drives regarding PELV.
NB!
It is the user's or certified electrician's re-
sponsibility to ensure correct earthing and
protection in accordance with applicable
national and local requirements and
standards.
Safety regulations
1. The VLT DriveMotor (FC motor) must be dis-
connected from mains if repair work is to be
carried out.
Check that the mains supply has been dis-
connected and that the necessary time has
passed (4 minutes).
2. Correct protective earthing of the equipment
must be established, the user must be pro-
tected against supply voltage, and the motor
must be protected against overload in ac-
cordance with applicable national and local
regulations.
Use of RCD's (ELCB relays) is described in
chapter 10.
3. The earth leakage currents are higher than
3.5 mA. This means that the FC motor re-
quires a fixed, permanent installation as well
as reinforced protective earthing.
Warning against unintended start
1. The motor can be brought to a stop by means
of digital commands, bus commands, or ref-
erences, while the frequency converter is
connected to mains.
If personal safety considerations make it nec-
essary to ensure that no unintended start
occurs,
these stop functions are not suffi-
cient .
2. While parameters are being changed, the
motor may start.
3. A motor that has been stopped may start if
faults occur in the electronics of the FC mo-
tor, or if a temporary overload or a fault in the
mains supply ceases.
VLT
®
FCM Series
MG.03.H6.02 - VLT
®
is a registered Danfoss trademark 5
