Bolt torques
Endshields and lid should be secured with the bolt
sizes and torque's detailed in the table below.
Endshield fixing bolt torques
FCM
Type
Frame size Bolt diameter Torque
Nm.
305-307
80 M5 5
311-315 90 M5 5
322-330 100 M6 (taptite) 8-10
340 112 M6 (taptite) 8-10
355-375 132 M8 (taptite) 29
LID screws torque: 2.2 - 2.4 Nm
Maintenance
Routine cleaning of the FC motor
Remove the fan cover and ensure that all air inlet holes
are completely free. Clean any dirt and obstructions
from behind the fan and along the ribs of the frame,
and between the motor and inverter part.
Periodic maintenance of motor part.
a. Remove the inverter part, the fan cover and
the fan which is keyed to the shaft extension.
Loosen and remove bearing cover screws
and endshield bolts/studs.The endshields
should then be eased off their spigots.
b. The rotor can now be carefully withdrawn
from the stator, taking care not to damage the
stator bore and both stator and rotor wind-
ings.
c. Having dismantled the motor, maintenance
can be carried out to remove all dirt. For this
purpose, the use of an air line supplying dry
compressed air under comparatively low
pressure is best, as a high velocity air-stream
can force dirt into the spaces between the
windings and insulation, etc. Grease-remov-
ing solvents can cause damage to impreg-
nating varnish or insulation
d. The FC-motor should be re-assembled in the
reverse order from dismantling, remember-
ing to ease endshields onto bearings and
spigots. DO NOT USE FORCE.
e. Before starting, check that the rotor revolves
freely. Ensure that the electrical connections
are correct.
f. Refit any pulley, coupling, sprocket etc.
which has been removed, being particularly
careful to ensure correct alignment with the
driven part, as misalignment will lead to ulti-
mate bearing trouble and shaft breakage.
g. When replacing screws and bolts, care
should be taken to use only those with the
requisite quality and tensile strength recom-
mended by the manufacturer. These must
also be of identical thread form and screw/
bolt length (see the table above).
Forced ventilation (FV) units
In some applications the fan built on to the motor shaft
do not give sufficient cooling for operation at low
speed. That problem is solved by mounting a FV unit.
Typical applications are for example conveyors, spin-
dles and other constant torque (CT) applications
where the customer wants a wide control range with-
out reduction in torque down to low speed.
The VLT Drive Motor yields full continuous torque
down to low speed with FV built on. The forced vent
enclosure is IP 66. Approved according to UL.
VLT
®
FCM Series
MG.03.H6.02 - VLT
®
is a registered Danfoss trademark 23
