Switching between read-out states I and II is effected
by pressing the [DISPLAY / STATUS] key.
MOTOR IS RUNNING
50.0 Hz
24.3% 30.2% 13.8A
In this state, data values for four operating values are
shown at the same time, giving the related unit, cf. ta-
ble. In the example, Reference, Torque, Current and
Frequency are selected as variables in the first and
second line.
• Read-out state III:
This read-out state can be held as long as the [DIS-
PLAY/STATUS] key is pressed. When the key is re-
leased, the system switches back to Read-out state II,
unless the key is pressed for less than approx. 1 sec.
50.0 Hz
SETUP
1
MOTOR IS RUNNING
REF% TORQUE CURR A
This is where parameter names and units for operating
variables in the first line are given - operating variable
2 remains unchanged.
Quick menu mode versus Menu mode
The FC motor series can be used for practically all as-
signments, which is why the number of parameters is
quite large. Also, this series offers a choice between
two programming modes - a Menu mode and a Quick
menu mode.
• The Quick menu takes the user through a
number of parameters that may be enough to
get the motor to run nearly optimally, if the
factory setting for the other parameters takes
the desired control functions into account, as
well as the configuration of signal inputs/out-
puts (control terminals).
• The Menu mode makes it possible to select
and change all parameters at the user's op-
tion. However, some parameters will be
"missing", depending on the choice of con-
figuration (parameter 100), e.g. open loop
hides all the PID parameters.
In addition to having a name, each parameter is linked
up with a number which is the same regardless of the
programming mode. In the Menu mode, the parame-
ters are divided into groups, with the first digit of the
parameter number (from the left) indicating the group
number of the parameter in question.
Regardless of the mode of programming, a change of
a parameter will take effect and be visible both in the
Menu mode and in the Quick menumode.
Quick Setup via Quick menu
The Quick Setup starts with pressing the [QUICK
MENU] key, which brings out the following read-out on
the display:
50.0 Hz
SETUP
1
QUICK MENU X OF Y
001 LANGUAGE
ENGLISH
At the bottom of the display, the parameter number
and name are given together with the status/value of
the first parameter under Quick Setup. The first time
the [Quick Menu] key is pressed after the unit has been
switched on, the read-outs will always start at pos. 1 -
see table below.
Parameter selection
The selection of parameter is effected by means of the
[+/-] keys. The following parameters are accessible:
Pos.: No.: Parameter: Unit:
1 001 Language
2 200 Direction of rotation
3 101 Torque characteristic
4 204 Min. reference [Hz]
5 205 Max. reference [Hz]
6 207 Ramp up time [sec.]
7 208 Ramp down time [sec.]
8 002 Local/remote control
9 003 Local reference
10 500 Bus address
VLT
®
FCM Series
MG.03.H6.02 - VLT
®
is a registered Danfoss trademark 31
