The scaling (parameters 336 and 337) does not influ-
ence the read-out. Min. and max. are determined by
the offset and gain adjustment of the AD-converter.
This value is updated every 20 ms.
543
Data read-out: Terminal 2, analogue in-
put
(ANALOG INPUT 2)
Value:
Unit: X.X V
Function:
This parameter can be read out via the serial commu-
nication port.
Description of choice:
The value shown indicates the signal value on terminal
2.
The scaling (parameters 338 and 339) does not influ-
ence the read-out. Min. and max. are determined by
the offset and gain adjustment of the AD-converter.
This value is updated every 20 ms.
561 Protocol
(PROTOCOL)
Value:
FC protocol (FC PROTOKOL) [0]
Modbus RTU [2]
Function:
There is a choice of three different protocols.
Description of choice:
Select the required control word protocol.
For further information about using the Modbus RTU,
see MG10SX.
570 Modbus parity and message framing
(M.BUS PAR./FRAME)
Value:
(EVEN/1 STOPBIT) [0]
(ODD/1 STOPBIT) [1]
(NO PARITY/1 STOPBIT) [2]
(NO PARITY/2 STOPBIT) [3]
Function:
This parameter sets up the drive’s Modbus RTU inter-
face to communicate properly with the master control-
ler. The parity (EVEN, ODD, or NO PARITY) must be
set to match the setting of the master controller.
Description of choice:
Select the parity that matches the setting for the Mod-
bus master controller. Even or odd parity is sometimes
used to allow a transmitted word to be checked for er-
rors. Because Modbus RTU uses the more efficient
CRC (Cyclic Redundancy Check) method of checking
for errors, parity checking is seldom used in Modbus
RTU networks.
NB!
Any change will disable use of display unit
(LCP2), and further programming also by
FC protocol.
571 Modbus communications timeout
(M.BUS COM.TIME.)
Value:
10 ms - 2000 ms
100 ms
Function:
This parameter determines the maximum amount of
time that the drive’s Modbus RTU will wait between
characters that are sent by the master controller.
When this amount of time expires, the drive’s Modbus
RTU interface will assume that it has received the en-
tire message.
Description of choice:
Generally, the value of 100 ms is sufficient for Modbus
RTU networks, although some Modbus RTU networks
may operate on a timeout value as short as 35 ms.
If this value is set too short, the drive’s Modbus RTU
interface may miss a part of the message. Since the
CRC check will not be valid, the drive will ignore the
message. The resulting retransmissions of messages
will slow communications on the network.
If this value is set too long, the drive will wait longer
than necessary to determine that the message is com-
pleted. This will delay the drive’s response to the mes-
sage and possibly cause the master controller to time
out. The resulting retransmissions of messages will
slow communications on the network.
VLT
®
FCM Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.03.H6.02 - VLT
®
is a registered Danfoss trademark 83
