Functions to programme, to control, and to monitor via bus (PROFIBUS) or by PC.
Parame-
ter No.
Function
Range/number of set-
tings/value
Factory setting
Data
type
Conv.
index
500 Bus address 1 - 126 1 5 0
501 Baudrate 300 - 9600 Baud/6 9600 Baud 5 0
502 Coasting 4 Logic or 5 0
503 Quick-stop 4 Logic or 5 0
504 DC-brake 4 Logic or 5 0
505 Start 4 Logic or 5 0
506 Reversing 4 Logic or 5 0
507 Selection of setup 4 Logic or 5 0
508 Selection of speed 4 Logic or 5 0
509 Bus jog 1 0.0 - f
MAX
10.0 Hz 6 -1
510 Bus jog 2 0.0 - f
MAX
10.0 Hz 6 -1
512 Telegram profile Profidrive/FC Drive FC Drive 5 0
513 Bus time interval 1 sec. 5 0
514 Bus time interval function 6 Off 5 0
515 Data read-out: Reference XXX.X 3 -1
516 Data read-out: Refer. unit Hz/rpm 4 -3
517 Data read-out: Feedback 4 -3
518 Data read-out: Frequency Hz 3 -1
519 Data read-out: Frequency x scale Hz 7 -2
520 Data read-out: Current A x 100 7 -2
521 Data read-out: Torque % 3 -1
522 Data read-out: Power kW 7 1
523 Data read-out: Power hp 7 -2
524 Data read-out: Motor voltage V 6 -1
525 Data read-out: DC link voltage V 6 0
527 Data read-out: FC therm. 0 - 100 % 5 0
528 Data read-out: Digital input 5 0
533 Data read-out: External reference -200.0 - +200.0 % 6 -1
534 Data read-out: Status word, binary 6 0
537 Data read-out: FC temperature °C 5 0
538 Data read-out: Alarm word, binary 7 0
539 Data read-out: Control word, binary 6 0
540 Data read-out: Warning word, 1 7 0
541 Data read-out: Warning word, 2 7 0
542 Data read-out: Terminal 1, analog input mA X 10 5 -4
543 Data read-out: Terminal 2, analog input V X 10 5 -1
561 Protocol FC protocol/Modbus RTU FC protocol 5 0
570 Modbus parity and message framing 4 Even/1stopbit 5 0
571 Modbus Communications timeout 10-2000 ms 100 ms 6 0
Functions to programme, to control, and to monitor via bus (PROFIBUS) or by PC.
Parame-
ter No.
Function Range/number of settings/value Factory setting
Data
type
Conv.
index
600 Operating data: Operating hours 0 - 130,000.0 hours 5 0
601 Operating data: Hours run 0 - 130,000.0 hours 7 73
603 Operating data: Number of power-up's 0 - 9999 7 73
604 Operating data: Number of overtemp. 0 - 9999 6 0
605 Operating data: Number of overvoltages 0 - 9999 6 0
615 Fault log, read-out: Error code Index XX - XXX 6 0
616 Fault log, read-out: Time Index XX - XXX 5 0
617 Fault log, read-out: Value Index XX - XXX 7 -1
619 Reset of hours-run counter No reset/reset No reset 3 0
620 Operation mode 3 Normal function 5 0
621 Nameplate: FC motor type Depends on unit 5 0
624 Nameplate: Software version no. Depends on unit 9 0
625 LCP version Depends on unit 9 0
626 Nameplate: Database identification no. Depends on unit 9 0
628 Nameplate: Application option type 9 -2
630 Nameplate: Communication option type 9 0
632 BMC software identification 9 0
633 Motor database identification 9 0
634 Unit identification for communication 9 0
635 Software part No. 9 0
678 Configure Control Card Depends on unit 5 0
VLT
®
FCM Series
102 MG.03.H6.02 - VLT
®
is a registered Danfoss trademark
