32
Using the projector
English
Setting the User 1/User 2 mode
There are two user-definable modes if the current available picture modes are not suitable for your need.
You can use one of the picture modes (except the selected User mode) as a starting point and customize
the settings.
1. In the Picture menu, highlight Picture Mode and press / to select User 1 or User 2 mode.
2. Press to highlight Reference Mode.
This function is only available when User 1 or User 2 mode is selected up in the Picture Mode sub-menu
item.
3. Press / to highlight a picture mode that is closest to your need.
4. Press to select a sub-menu item to be changed and adjust the value with / . See "Fine-tuning
the picture quality" on page 33 and "Advanced picture quality controls" on page 34 for details.
5. When all settings have been done, press MENU/EXIT to save and leave the settings.
Renaming user modes
You can change User 1 and User 2 to the names easy to be identified or understood by the users of this
projector. The new name can be up to 8 characters including English letters (A-Z, a-z), digits (0-9), and
space (_).
To rename user modes:
1. Make sure you have selected User 1 or User 2 as your picture mode.
If you are not under User 1 or User 2 mode, the projector will automatically select User 1 as the user mode
to rename.
2. In the Picture menu, highlight Rename User Mode and press MODE/ENTER to display the
virtual keypad.
3. Use // / and ENTER keys to select the letters on the virtual keypad to type in desired name.
4. When done, press MENU/EXIT to leave the virtual keypad.
Resetting the picture mode
All of the adjustments you’ve done in the Picture menu can be returned to the factory preset values
with a key press on the highlight of Reset.
To reset the picture mode to the preset factory values:
1. In the Picture menu, highlight Picture Mode and press / to select the picture mode (including
User 1 or User 2) you want to reset.
2. Press to highlight Reset Picture Settings and press MODE/ENTER.
3. Press / to select Current or All Picture modes and press MODE/ENTER. The confirmation
message is displayed.
4. Press / to highlight Reset and press MODE/ENTER. The picture mode will return to the
factory preset settings.
5. Repeat steps 1-4 if you want to reset other picture modes.
Do not confuse the Reset Picture Settings function here with the Reset All Settings in the System Setup:
Advanced menu. The Reset All Settings function returns most of the settings to the factory preset values
system wide. See "Reset All Settings" on page 58 for details.
