43
Using the projector
English
Setting the lamp mode
This projector provides two lamp modes for different purposes:
You can perform one of the following methods to choose a lamp mode according to your preference.
Using the remote control:
1. Press Lamp Mode on your remote control, the lamp mode page is displayed.
2. Press to highlight your preferred lamp mode and press MODE/ENTER.
Using the OSD menu:
1. Press MENU/EXIT and then press / until the System Setup: Advanced menu is highlighted.
2. Press to highlight Lamp Settings and press MODE/ENTER.
3. Press to highlight Lamp Mode and press MODE/ENTER.
4. Press to highlight your preferred lamp mode and press MODE/ENTER.
A slight variation in the picture brightness and colors may be observed during the very short time of
switching lamp modes.
Lamp mode User benefit Suitable environment
Normal
(The lamp is used in normal mode)
• Delivering bright and clear images
• Suitable for high-ambient-light environments
• Allowing continuous and non-stop operation under
critical situations
Large, well lit meeting rooms
or auditoriums
Economic
(The lamp is used in economic mode)
• Extending the lamp life
• Allowing continuous and non-stop operation under
critical situations
Small-mid boardrooms
