Adjusting the sound
The sound adjustments made (such as functions shown below) will have an effect on the projector
speaker(s). Be sure you have made a correct connection to the projector audio input. See "Connecting to
video equipment" on page 17 for how the audio input is connected.
• Each time when you select a different source, the projector also changes the sound settings to which was
last set for that particular source.
• Sound adjustments cannot be made during Quick Search.
Muting the sound
To temporarily turn off the sound:
1. Press MENU/EXIT to open the OSD menu and press / to highlight the Source menu.
2. Press to highlight Audio Settings and press MODE/ENTER. The Audio Settings page is
displayed.
3. Press to highlight Mute and press / to select On.
If available, you can also press MUTE on the remote control to toggle projector audio between on and off.
Adjusting the sound level
To adjust the sound level, press VOLUME+/VOLUME- on the remote control, or:
1. Repeat steps 1-2 from above.
2. Press to highlight Volume and press / to select a desired sound level.
Adjusting the Microphone sound level
To adjust the microphone sound level:
1. Repeat steps 1-2 from above.
2. Press to highlight Microphone Volume and press / to select a desired sound level.
Turning off the Power On/Off Ring Tone
To turn off the ring tone:
1. Repeat steps 1-2 from above.
2. Press to highlight Power On/Off Ring Tone and press / to select Off.
The only way to change Power On/Off Ring Tone is setting On or Off here. Setting the sound mute or
changing the sound level will not affect the Power On/Off Ring Tone.
