41
Using the projector
English
Using the test pattern
The projector is able to display the grid test pattern. It helps you adjust
the image size and focus on checking that the projected image is free
from distortion.
To display the test pattern:
1. Press MENU/EXIT to open the OSD menu and press / to
highlight the System Setup: Basic menu.
2. Press to highlight Test Pattern and press / to select On.
