51
Using the projector
English
Main menu Sub-menu Options
Display
Wall Color
Off/Light Yellow/Pink/Light Green/Blue/
Blackboard
Aspect Ratio Auto/Real/4:3/16:9/16:10
Overscan Adjustment 0/1/2/3
2D Keystone H: -30 ~ 0 ~ 30/ V: -30 ~ 0 ~ 30
Corner Fit
Top Left/Top Right/Bottom Left/
Bottom Right
3D
3D Mode
Auto/Off/Frame Sequential/Frame
Packing/Top-Bottom/Side-by-Side
3D Sync Invert Disable/Invert
Save 3D Settings
3D Settings 1/3D Settings 2/
3D Settings 3
Apply 3D Settings
3D Settings 1/3D Settings 2/
3D Settings 3/Off
Teaching Template
Blackboard Off/Letter Formation/Worksheet/Coordinate Chart
Whiteboard Off/Letter Formation/Worksheet/Coordinate Chart
Source
Quick Search On/Off
HDMI Setting HDMI Format Auto/Full/Limit
Audio Settings
Mute On/Off
Volume 0 ~ 5 ~ 10
Microphone Volume 0 ~ 5 ~ 10
Power On/Off Ring
To n e
On/Off
Position H: -10 ~ 0 ~ 10/ V: -10 ~ 0 ~ 10
Phase 0 ~ Auto ~ 31
H. Size -15 ~ 0 ~ 15
System
Setup: Basic
Language
Projector
Installation
Front/Rear/Rear Ceiling/Front Ceiling
Menu Settings
Menu Display Time 5 sec/10 sec/20 sec/30 sec/Always
Menu Position
Center/Top-Left/Top-Right/Bottom-
Right/Bottom-Left
Reminder Message On/Off
Operation Settings
Direct Power On On/Off
Signal Power On On/Off
Auto Power Off
Disable/3 min/10 min/15 min/20 min/25
min/30 min
Blank Timer
Disable/5 min/10 min/15 min/20 min/25
min/30 min
Sleep Timer
Disable/30 min/1 hr/2 hr/3 hr/4 hr/8 hr/
12 hr
Remote Receiver Front/Rear/Front+Rear/Off
Panel Key Lock On/Off
Background Color BenQ/Black/Blue/Purple
Splash Screen BenQ/Black/Blue
Test Pattern On/Off
