70
Additional information
English
Timing chart
Supported timing for PC input
Format Resolution
Refresh rate
(Hz)
H. Frequency
(KHz)
Pixel Frequency
(MHz)
640 x 480
VGA_60* 59.94 31.469 25.175
VGA_72 72.809 37.861 31.5
VGA_75 75 37.5 31.5
VGA_85 85.008 43.269 36
720 x 400 720 x 400_70 70.087 31.469 28.3221
800 x 600
SVGA_60* 60.317 37.879 40
SVGA_72 72.188 48.077 50
SVGA_75 75 46.875 49.5
SVGA_85 85.061 53.674 56.25
SVGA_120**
(Reduce Blanking)
119.854 77.425 83
1024 x 768
XGA_60* 60.004 48.363 65
XGA_70 70.069 56.476 75
XGA_75 75.029 60.023 78.75
XGA_85 84.997 68.667 94.5
XGA_120**
(Reduce Blanking)
119.989 97.551 115.5
1152 x 864 1152 x 864_75 75 67.5 108
1024 x 576**** Notebook Timing 60 35.82 46.996
1024 x 600**** Notebook Timing 64.995 41.467 51.419
1280 x 720 1280 x 720_60* 60 45 74.25
1280 x 768 1280 x 768_60* 59.87 47.776 79.5
1280 x 800
WXGA_60* 59.81 49.702 83.5
WXGA_75 74.934 62.795 106.5
WXGA_85 84.88 71.554 122.5
WXGA_120**
(Reduce Blanking)
119.909 101.563 146.25
1280 x 1024
SXGA_60*** 60.02 63.981 108
SXGA_75 75.025 79.976 135
SXGA_85 85.024 91.146 157.5
1280 x 960
1280 x 960_60*** 60 60 108
1280 x 960_85 85.002 85.938 148.5
1360 x 768 1360 x 768_60*** 60.015 47.712 85.5
1440 x 900 WXGA+_60*** 59.887 55.935 106.5
1400 x 1050 SXGA+_60*** 59.978 65.317 121.75
1600 x 1200 UXGA*** 60 75 162
1680 x 1050 1680 x 1050_60*** 59.954 65.29 146.25
