42
Using the projector
English
Using the teaching templates
The projector provides several preset patterns for various teaching purposes. To activate the pattern:
1. Press MENU/EXIT to open the OSD menu and press / to highlight the Display menu.
2. Press to highlight Teaching Template and press MODE/ENTER.
3. Press / to highlight Blackboard or Whiteboard.
4. Press / to select the desired pattern and press MODE/ENTER.
Te a c h i n g Te m p l a t e Whiteboard Blackboard
Letter Formation
Worksheet
Coordinate Chart
