Movitec; 4B; n = 2900 rpm

K95000400/2

0 1 2 3 4 5 6 7

Q [m³/h]

0 10 20 30

Q [US.gpm]

0 5 10 15 20 25

Q [IM.gpm]

100

150

200

250

H [m]

200

400

600

800

H [ft]

0.0 0.5 1.0 1.5

Q [l/s]

NPSH

[m]

NPSH

[ft]

Eta [%]

0.0

0.15

P [kW]

0.0

0.2

P [hp]

0 1 2 3 4 5 6 7

Q [m³/h]

4/26 4,0kW

4/24 4,0kW

4/22 4,0kW

4/20 3,0kW

4/18 3,0kW

4/16 3,0kW

4/14 2,2kW

4/12 2,2kW

4/11 2,2kW

4/10 1,5kW

4/9 1,5kW

4/8 1,5kW

4/7 1,1kW

4/6 1,1kW

4/5 0,75kW

4/4 0,55kW

4/3 0,55kW

4/2 0,37kW

St=1

St = Number of stages

The power input P is indicated per stage
