Movitec; 15B; n = 1450 rpm

Mov15TNG1450/2

0 2 4 6 8 10 12

Q [m³/h]

0 10 20 30 40 50

Q [US.gpm]

0 10 20 30 40

Q [IM.gpm]

H [m]

100

150

200

H [ft]

0 1 2 3

Q [l/s]

0.2

NPSH

[m]

NPSH

[ft]

Eta [%]

0.1

0.02

P [kW]

0.05

0.15

P [hp]

0 2 4 6 8 10 12

Q [m³/h]

15/17 2,2kW

15/15 2,2kW

15/13 1,5kW

15/11 1,5kW

15/10 1,5kW

15/9 1,1kW

15/8 1,1kW

15/7 1,1kW

15/6 0,75kW

15/5 0,55kW

15/4 0,55kW

15/3 0,55kW

15/2 0,55kW

15/1 0,55kW

St=1

St = Number of stages

The power input P is indicated per stage
