KSB Movitec LHV025/03 [38/60] High pressure pumps
![KSB Movitec VF06/04 [38/60] High pressure pumps](/views2/1586680/page38/bg26.png)
Movitec, 10B, n = 2900 rpm
F1
F2
E1
E2
P
G 3/8
A
Movitec V/VS, VV/VSF, VT/VST,
VF/VSF, VCF
Dimensions
Number of
stages
E1 E2
P
24)
Movitec
V/VS; VV/VSV;
VT/VST
VF/VSF; VCF
F1 F2 F1 F2
[mm]
1 160 150 - 621 346 621 346
2 160 150 - 621 346 621 346
3 160 150 - 647 372 647 372
4 185 160 - 679 409 679 409
5 185 160 - 720 435 720 435
6 185 160 - 747 462 747 462
7 205 175 - 828 498 828 498
8 205 175 - 855 525 855 525
9 205 175 - 891 551 891 551
10 205 175 - 918 578 918 578
11 205 175 - 944 604 944 604
13 260 220 300 1102 737 1102 737
15 260 220 300 1155 790 1155 790
17 260 220 300 1208 843 1208 843
19 260 220 300 1261 896 1261 896
21 260 220 300 1314 949 1314 949
100
215
247
80
130
184
200
G 6/4
G 6/4
G 1/4
4 × Ø14
A
Movitec V/VS
4 × Ø14
215
247
130
184
261
80
Ø 60,3
G 1/4
Ø 60,3
A
Movitec VV/VSV
215
247
80
G 1/4
Ø 64
4 × Ø 14
Ø 64
130
184
200
A
Movitec VT/VST
Ø150
Ø110
Ø85
215
247
4 × Ø19
4 × Ø14
80
DN 40
DN 40
130
184
280
G 1/4
A
Movitec VF/VSF
215
247
Ø150
Ø110
Ø85
80
4 × Ø14
4 × Ø19
G 1/4
DN 40
DN 40
130
184
280
A
Movitec VCF
24)
Only relevant for motors > 5.5 kW
High-pressure Pumps
High-pressure In-line Pumps
38
Movitec
