Kohler Command PRO EFI ECH749 [45/180] Efi system electronic throttle body etb ech
![Kohler Command PRO EFI ECH749 [45/180] Efi system electronic throttle body etb ech](/views2/1597403/page45/bg2d.png)
4524 690 01 Rev. O KohlerEngines.com
EFI SYSTEM-ELECTRONIC THROTTLE BODY (ETB) ECH
Troubleshooting-Oxygen (O2) Sensor
Condition Possible Cause Conclusion
Continuous low voltage output (less
than 400mV) observed with throttle
openings of 40% or more (lean
biased condition).
Fault codes P0131, P0171, or P0174
may set.
Shorted sensor or sensor circuit.
Shorted lead wire.
Wiring shorted to ground.
Replace sensor or replace and
properly route wiring.
Upstream or downstream exhaust
leaks observed.
Air leak at sensor.
Repair all exhaust leaks and torque
sensor to appropriate torque.
Style 1 (Smaller Sensor)
18 N·m (159 in. lb.).
Style 2 (Larger Sensor)
50.1 N·m (37 ft. lb.).
Restricted fuel supply. Resolve fuel supply issues from tank
to engine. Test fuel pressure. Perform
repairs necessary.
Misfi re A misfi re causing incomplete
combustion will result in lean (low
voltage) values.
Lean biased sensor failure. Replace sensor.
Continuous high voltage output
(600mV or more) observed with
throttle openings of 40% or less (rich
biased condition).
Fault codes P0172 or P0132 may set.
Silica poisoning. Replace sensor. Identify and resolve
root cause.
Contaminated gasoline. Purge fuel system and retest.
Wiring shorted to voltage. Replace damaged harness.
Overly rich condition due to
unmetered fuel entering combustion
chamber.
Test fuel pressure. Inspect fuel pump
vent and evaporative emissions
hoses for raw fuel fl ow.
Inspect engine oil for fuel
contamination; drain and refi ll if
suspect.
Perform repairs as necessary.
Cold engine. Engine temperature
below 150°F (66°C) as displayed by
KOHLER
®
Diagnostic System (KDS)
Gen 2, see Tools and Aids.
Normal operation, or engine operated
in an excessively cold environment.
Rich biased sensor failure. Replace sensor.
No activity from sensor.
KDS tool displays
1.015 Volts continuously.
Fault codes P0031 or P0032 may set.
Heater circuit open or shorted. Replace sensor.
Engine keyed ON with sensor
disconnected.
Historic codes.
Secure and/or confi rm sensor
connection and clear codes.
Contaminated gasoline. Purge fuel system and retest.
