Grillo GH 9 [10/71] Putting the machine into service

Translation of the Original Instructions

TECHNICAL SPECIFICATIONS

ENGINE: GH7: HONDA GX200 OHV 196 cm³ 5,5 HP 4,1 kW @ 3600 r.p.m., single cylinder petrol

engine.

. GH9: HONDA GX270 OHV 270 cm³ 8,4 HP 6,3 kW @ 3600 r.p.m., single cylinder petrol engine.

STARTER: recoil starter

FUEL TANK: 3,1 litres (GH7) – 5,3 litres (GH9)

TRANSMISSION: hydrostatic

DRIVE: 2WD

SPEED: forward gear from 0 to 6 km/h continuously variable - reverse gear from 0 to 3 km/h

DRIVE WHEELS: TRACTOR wheels 16×6.50-8

FRONT WHEELS: solid and puncture-proof wheels

PARKING BRAKE: via pedal

PTO: @ 965 r.p.m.

HANDLEBAR: quickly adjustable both vertically and laterally

CUTTING SYSTEM: rotor equipped with Y-shaped blades

CUTTING HEIGHT: from 30 to 110 mm, quick adjustment via flywheel

CUTTING WIDTH: 680 mm

ROTOR SPEED: 2400 r.p.m.

SIZE: Length 2000 mm – Width 800 mm – Height 1000 m.

WEIGHT: 150 kg (GH 7) – 162 Kg (GH 9).

PUTTING THE MACHINE INTO SERVICE

1) Check that the machine has not been damaged during transport.

2) Remove the machine from the packaging, paying attention not to damage levers and cables.

Use an appropriate lifting machine (min. capacity 100 kg). Before putting the machine on the

ground mount the wheels, making sure the fixing nuts are properly fastened (fig. 2, n. 19).

3) Check the engine oil level (fig. 5, B).

4) Mount the forward gear rod (fig. 2, n. 3).

5) Mount the implement (e.g. all purpose flail, brush…) and fasten the nuts tightly (fig. 6).

6) Check the tyre pressure: 1,2 BAR for the drive wheels 16×6.50-8 and 1,5 for the front 4.00-8

wheels

IMPORTANT

7) Fill the tank with fuel using a funnel provided with a fine filter

8) Check the various liquid level with the machine in horizontal position

RUNNING-IN – IMPORTANT!

Drain the engine oil and fill in with fresh one after the first 5 working hours (use SAE30 oil). Check

that there are no oil losses or loose screws, especially those fixing the Y-shaped blades on the

rotor. After a few working hours, if necessary adjust the forward gear belt tension (fig. 4, B) and the

PTO belt tension (fig. 4, A).
