GeneralThechillerwillbedesignedandmanufacturedinaccordancewiththefollowingEuropeandirectives:

•Constructionofpressurevessel2014/68/EU

•MachineryDirective2006/42/EC

•LowVoltage2014/35/EU

•ElectromagneticCompatibility2014/30/EU

•Electrical&SafetycodesEN60204–1/EN60335-2-40

•ManufacturingQualityStandardsUNI–UNIENISO1400

Toavoidanylosses,theunitwillbetestedatfullloadinthefactory(atthenominalworkingconditionsand

-outsideairtemperaturefrom...............°Cto...............°C

-evaporatorleavingfluidtemperaturebetween...............°Cand...............°C





RefrigerantHFC134a

PerformanceChillershallsupplythefollowingperformances:

•Numberofchiller(s):...............unit(s)

•Coolingcapacityforsinglechiller:...............kW

•Powerinputforsinglechillerincoolingmode:...............kW

•Heatexchangerenteringwatertemperatureincoolingmode:...............°C

Operatingvoltagerangeshouldbe400V±10%,3ph,50Hz(or380V±10%,3ph,60Hz),voltageunbalance

maximum3%,withoutneutralconductorandshallonlyhaveonepowerconnectionpoint.

Unit descriptionChillershallincludeoneortwoindependentrefrigerantcircuits,semi-hermetictyperotary

singlescrewcompressors,refrigerantcooledinverterdriveforeachcompressor,electronicexpansiondevice

(EEXV),directexpansion‘shell&tube’orPHEevaporator,air-cooledcondensersectionmadewithaluminum

Microchanneltechnology,R-134arefrigerant,lubricationsystem,motorstartingcomponents,dischargeline

shut-offvalve,suctionlineshut-offvalve,controlsystemandallcomponentsnecessaryforasafeandstable

unitoperation.

Thechillerwillbefactoryassembledonarobustbaseframemadeofgalvanizedsteel,protectedbyanepoxy

DimensionsUnitdimensionsshallnotexceedfollowingindications:

-Unitlength...............mm

-Unitwidth...............mm

-Unitheight...............mm

Compressors

•Semi-hermetic,single-screwtypewithonemainhelicalrotormeshingwiththegaterotor.Thegaterotorwill

beconstructedofacarbonimpregnatedengineeredcompositematerial.Thegaterotorsupportswillbe

constructedofcastiron.

•Eachcompressorshallbefittedwithinverterdriveforvariablecapacitycontrol.Invertershallbeintegrated

•Refrigerantsystemdifferentialpressureshallprovideoilflowthroughservicereplaceable,0.5micron,full

flow,cartridgetypeoilfilterinternaltocompressor.

•Refrigerantsystemdifferentialpressureshallprovideoilinjectiononallmovingcompressorpartstocorrectly

lubricatethem.Electricaloilpumplubricatingsystemisnotacceptable.

•Thecompressor’soilcoolingmustberealized,whennecessary,byrefrigerantliquidinjection.External
