EWAD~TZ-PL B
6"
4"
4"
4"
3"
3"
mm
Evaporatorwaterinlet/outlet
PIPING CONNECTIONS
2
1
1
1
1
1
No.
N.ofcircuits
77
58
51
50
49
49
kg
Refrigerantcharge
R134a
R134a
R134a
R134a
R134a
R134a
Refrigeranttype
REFRIGERANT CIRCUIT
73
72
72
71
72
71
dB(A)
SoundPressurelevel@1mdistance-
Cooling
93.5
92
91.5
91
91.5
91
dB(A)
SoundPower-Cooling***
SOUND LEVEL
2
1
1
1
1
1
No.
Quantity
20.0
10.0
10.0
10.0
10.0
10.0
l
Oilcharge
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Type
COMPRESSOR
8.4
7.0
5.6
5.6
5.6
5.6
kW
Motorinput
700
700
700
700
700
700
rpm
Speed
12
10
8
8
8
8
No.
Quantity
44415
37013
29610
29610
29610
29610
l/s
Nominalairflow
800
800
800
800
800
800
mm
Diameter
BRS
BRS
BRS
BRS
BRS
BRS
Drive*
DPT
DPT
DPT
DPT
DPT
DPT
Type*
FAN
MCH
MCH
MCH
MCH
MCH
MCH
Type*
AIR HEAT EXCHANGER
CC
CC
CC
CC
CC
CC
Insulationmaterial*
20.4
21.5
17.1
13.4
11.0
10.6
kPa
Waterpressuredrop**
18.1
15.5
13.5
11.7
10.3
8.8
l/s
Waterflowrate
255
49.5
49.5
49.5
49.5
49.5
l
WaterVolume
S&T
PHE
PHE
PHE
PHE
PHE
Type*
WATER HEAT EXCHANGER
5020
3085
2835
2834
2823
2823
kg
OperatingWeight
4765
3035
2785
2784
2773
2773
kg
UnitWeight
WEIGHT
5883
4983
4083
4083
4083
4083
mm
Length
2258
2258
2258
2258
2258
2258
mm
Width
2483
2483
2483
2483
2483
2483
mm
Height
DIMENSIONS
GPSS
GPSS
GPSS
GPSS
GPSS
GPSS
Material*
IW
IW
IW
IW
IW
IW
Colour*
CASING
6.19
6.00
5.99
5.96
5.99
6.09
IPLV
5.67
5.55
5.59
5.58
5.66
5.70
ESEER
3.62
3.37
3.38
3.55
3.56
3.64
EER
104
95.9
83.4
68.7
60.7
50.5
kW
Unitpowerinput-Cooling
19
27
29
34
29
34
%
Capacitycontrol-Minimumcapacity
Stepless
Stepless
Stepless
Stepless
Stepless
Stepless
Capacitycontrol-Type
379
323
281
244
216
183
kW
Capacity-Cooling
COOLING PERFORMANCE
EWAD350TZ
-PL B2
EWAD300TZ
-PL B1
EWAD290TZ
-PL B1
EWAD240TZ
-PL B1
EWAD220TZ
-PL B1
EWAD190TZ
-PL B1
MODEL
All the perfrormances (Cooling capacity, unit power input in cooling and EER) are based on the following conditions: evaporator 12.0/7.0°C; ambient
35.0°C, unit at full load operation; operating f
luid: Water
; fouling factor = 0.
(*) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; PHE: Plate Heat Exchanger; S&T: Single Pass Shell & Tube; MCH: Microchannel; CC:
Closed Cell; DPT: Direct Propeller Type; DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(**) The value referes to the pressur drop in the evaporator only.
(***) Sound power level (referred to evaporator 12/7°C, ambient 35°C full load operation) are mesuared in accordance with ISO 9614 and Eurovent 8/1
for Eurovent certified units. The certification refers only to the overall sound power level, the sound pressure is calculated from the sound power level and
are for information only and not cosidered binding. The minimum capacity indicated is referred to unit operating at standard Eurovent conditons.
Dimensions and weights are for indication only and not considered binding. Before desining the installation, consult the offical drawings available from the
factory at request. All the data are referred to standard unit without options. Data are subject to change without notice.
37/104
TECHNICAL SPECIFICATIONS
