EWAD~TZ-XL B
5"
4"
4"
4"
3"
3"
mm
Evaporatorwaterinlet/outlet
PIPING CONNECTIONS
2
1
1
1
1
1
No.
N.ofcircuits
64
51
51
40
39
36
kg
Refrigerantcharge
R134a
R134a
R134a
R134a
R134a
R134a
Refrigeranttype
REFRIGERANT CIRCUIT
73
73
72
72
72
72
dB(A)
SoundPressurelevel@1mdistance-
Cooling
93.5
92.5
91.5
91
91.5
91
dB(A)
SoundPower-Cooling***
SOUND LEVEL
2
1
1
1
1
1
No.
Quantity
20.0
10.0
10.0
10.0
10.0
10.0
l
Oilcharge
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Type
COMPRESSOR
8.0
6.4
6.4
4.8
4.8
4.8
kW
Motorinput
700
700
700
700
700
700
rpm
Speed
10
8
8
6
6
6
No.
Quantity
37774
30219
30219
22664
22664
22664
l/s
Nominalairflow
800
800
800
800
800
800
mm
Diameter
VFD
VFD
VFD
VFD
VFD
VFD
Drive*
DPT
DPT
DPT
DPT
DPT
DPT
Type*
FAN
MCH
MCH
MCH
MCH
MCH
MCH
Type*
AIR HEAT EXCHANGER
CC
CC
CC
CC
CC
CC
Insulationmaterial*
34.3
21.0
17.1
16.2
13.2
16.4
kPa
Waterpressuredrop**
17.3
15.0
13.2
11.5
10.1
8.6
l/s
Waterflowrate
158
49.5
49.5
37.3
37.3
26.1
l
WaterVolume
S&T
PHE
PHE
PHE
PHE
PHE
Type*
WATER HEAT EXCHANGER
4480
2835
2835
2474
2462
2403
kg
OperatingWeight
4322
2785
2785
2436
2424
2377
kg
UnitWeight
WEIGHT
4983
4083
4083
3183
3183
3183
mm
Length
2258
2258
2258
2258
2258
2258
mm
Width
2483
2483
2483
2483
2483
2483
mm
Height
DIMENSIONS
GPSS
GPSS
GPSS
GPSS
GPSS
GPSS
Material*
IW
IW
IW
IW
IW
IW
Colour*
CASING
5.94
5.76
5.68
5.64
5.69
5.71
IPLV
5.39
5.32
5.25
5.15
5.20
5.28
ESEER
3.30
3.13
3.30
3.30
3.34
3.46
EER
109
100
83.9
72.5
63.2
52.1
kW
Unitpowerinput-Cooling
17
25
29
34
29
34
%
Capacitycontrol-Minimumcapacity
Stepless
Stepless
Stepless
Stepless
Stepless
Stepless
Capacitycontrol-Type
360
313
276
239
211
180
kW
Capacity-Cooling
COOLING PERFORMANCE
EWAD360TZ
-XL B2
EWAD320TZ
-XL B1
EWAD290TZ
-XL B1
EWAD240TZ
-XL B1
EWAD220TZ
-XL B1
EWAD190TZ
-XL B1
MODEL
All the perfrormances (Cooling capacity, unit power input in cooling and EER) are based on the following conditions: evaporator 12.0/7.0°C; ambient
35.0°C, unit at full load operation; operating f
luid: Water
; fouling factor = 0.
(*) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; PHE: Plate Heat Exchanger; S&T: Single Pass Shell & Tube; MCH: Microchannel; CC:
Closed Cell; DPT: Direct Propeller Type; DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(**) The value referes to the pressur drop in the evaporator only.
(***) Sound power level (referred to evaporator 12/7°C, ambient 35°C full load operation) are mesuared in accordance with ISO 9614 and Eurovent 8/1
for Eurovent certified units. The certification refers only to the overall sound power level, the sound pressure is calculated from the sound power level and
are for information only and not cosidered binding. The minimum capacity indicated is referred to unit operating at standard Eurovent conditons.
Dimensions and weights are for indication only and not considered binding. Before desining the installation, consult the offical drawings available from the
factory at request. All the data are referred to standard unit without options. Data are subject to change without notice.
29/104
TECHNICAL SPECIFICATIONS
