EWAD~TZ-XR B
6"
6"
6"
6"
5"
5"
mm
Evaporatorwaterinlet/outlet
PIPING CONNECTIONS
2
2
2
2
2
2
No.
N.ofcircuits
96
89
80
80
74
64
kg
Refrigerantcharge
R134a
R134a
R134a
R134a
R134a
R134a
Refrigeranttype
REFRIGERANT CIRCUIT
71
70
70
70
70
70
dB(A)
SoundPressurelevel@1mdistance-
Cooling
92
91
91
91
91
90
dB(A)
SoundPower-Cooling***
SOUND LEVEL
2
2
2
2
2
2
No.
Quantity
20.0
20.0
20.0
20.0
20.0
20.0
l
Oilcharge
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Inverter
DrivenSingle
Screw
Type
COMPRESSOR
12.8
11.2
9.6
9.6
9.6
8.0
kW
Motorinput
700
700
700
700
700
700
rpm
Speed
16
14
12
12
12
10
No.
Quantity
59299
51745
44475
44475
44475
37774
l/s
Nominalairflow
800
800
800
800
800
800
mm
Diameter
VFD
VFD
VFD
VFD
VFD
VFD
Drive*
DPT
DPT
DPT
DPT
DPT
DPT
Type*
FAN
MCH
MCH
MCH
MCH
MCH
MCH
Type*
AIR HEAT EXCHANGER
CC
CC
CC
CC
CC
CC
Insulationmaterial*
30.4
27.1
41.0
36.6
39.7
31.2
kPa
Waterpressuredrop**
30.5
28.6
26.9
25.3
22.6
20.0
l/s
Waterflowrate
255
255
255
255
158
158
l
WaterVolume
S&T
S&T
S&T
S&T
S&T
S&T
Type*
WATER HEAT EXCHANGER
5880
5527
5255
5255
4960
4650
kg
OperatingWeight
5625
5272
5000
5000
4802
4492
kg
UnitWeight
WEIGHT
7683
6783
5883
5883
5883
4983
mm
Length
2258
2258
2258
2258
2258
2258
mm
Width
2483
2483
2483
2483
2483
2483
mm
Height
DIMENSIONS
GPSS
GPSS
GPSS
GPSS
GPSS
GPSS
Material*
IW
IW
IW
IW
IW
IW
Colour*
CASING
5.81
5.85
5.83
5.74
5.78
5.98
IPLV
5.34
5.32
5.33
5.29
5.24
5.31
ESEER
3.15
3.11
3.09
3.22
3.24
3.16
EER
203
192
181
164
145
132
kW
Unitpowerinput-Cooling
13
14
15
16
17
16
%
Capacitycontrol-Minimumcapacity
Stepless
Stepless
Stepless
Stepless
Stepless
Stepless
Capacitycontrol-Type
638
598
562
528
472
417
kW
Capacity-Cooling
COOLING PERFORMANCE
EWAD660TZ
-XR B2
EWAD610TZ
-XR B2
EWAD570TZ
-XR B2
EWAD540TZ
-XR B2
EWAD450TZ
-XR B2
EWAD420TZ
-XR B2
MODEL
All the perfrormances (Cooling capacity, unit power input in cooling and EER) are based on the following conditions: evaporator 12.0/7.0°C; ambient
35.0°C, unit at full load operation; operating f
luid: Water
; fouling factor = 0.
(*) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; PHE: Plate Heat Exchanger; S&T: Single Pass Shell & Tube; MCH: Microchannel; CC:
Closed Cell; DPT: Direct Propeller Type; DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(**) The value referes to the pressur drop in the evaporator only.
(***) Sound power level (referred to evaporator 12/7°C, ambient 35°C full load operation) are mesuared in accordance with ISO 9614 and Eurovent 8/1
for Eurovent certified units. The certification refers only to the overall sound power level, the sound pressure is calculated from the sound power level and
are for information only and not cosidered binding. The minimum capacity indicated is referred to unit operating at standard Eurovent conditons.
Dimensions and weights are for indication only and not considered binding. Before desining the installation, consult the offical drawings available from the
factory at request. All the data are referred to standard unit without options. Data are subject to change without notice.
33/104
TECHNICAL SPECIFICATIONS
