Gigabyte G481-HA0 (rev. 200) [18/124] 2 rear view

System Appearance - 18 -

2-2 Rear View

PSU #1

PSU #2

PSU #3

234

No.

Description

No.

Description

GPU Fan Module

10/100/1000 Server Management LAN Port

PCIe x16 Slot x 8

LAN Module

10GbE LAN Port x 2 (optional)

Power Supply Unit x 3 (PSU #1 to #3)
