ASRock TR-KNL [12/26] Inside view
![ASRock TR-KNL [12/26] Inside view](/views2/1694137/page12/bgc.png)
8 9
English
2.4 Inside View
1
4
2
3
5
6
7
HDD0
HDD1
HDD2
HDD3
HDD4
8
Slot 2
Slot 7
No. Description
1 1 x Power Supply Unit (600W)
2 Rear System Fan
3 7 x Add-on Card Slots*
*e TR-KNL system only supports Slot 2 and Slot 7 for add-on card installation.
4 Server Board
5 Front System Fan 1
6 Front System Fan 2
7 Media Bays*
8 Drive Bays*
*Please be noted that the functions are supported depending on the type of the server board.
