ASRock TR-KNL [6/26] Specifications
![ASRock TR-KNL [6/26] Specifications](/views2/1694137/page6/bg6.png)
2 3
English
1.2 Specications
TR-KNL
System Physical Status
Form Factor Pedestal
Dimension
(D x W x H)
560 x 200 x 430 mm (22" x 7.9" x 16.9")
Support MB Size CRB-KNLMB (SSI EEB, 12''x13'')
Front Panel
Buttons • Power button
• System reset button
LEDs • Power LED
• UID LED
• LAN LED
• Hard drive activity LED
• System Fail LED
I/O Port 2 x USB 3.0 ports
Drive Bay
Internal Side 3.5" or 2.5" x 2 SATA HDD (6Gb/s)
System Cooling (per node)
Fan 120 x 25 mm Fan x3
Power Supply
Type Single
Output Watts 600 W
1. Please contact ASRock Rack sales for target system conguration.
2. Please refer to the user manual of the motherboard you use for detailed information about
motherboard components and features.
