ASRock TR-KNL [20/26] English
![ASRock TR-KNL [20/26] English](/views2/1694137/page20/bg14.png)
16 17
English
Replacing the Rear System Fan
1. Unplug the fan connecter. Release the four screws that secure the fan to the chassis.
2. Remove the failed fan.
3. Reverse the procedures to install the rear fan.
1
2
