ASRock C3758D4I-4L [70/97] English
![ASRock C3758D4I-4L [70/97] English](/views2/1694241/page70/bg46.png)
64 65
English
e default login information for the IPMI web interface is:
Username: admin
Password: admin
For more instructions on how to set up remote control environment and use the IPMI man-
agement platform, please refer to the IPMI Conguration User Guide or go to the Support
website at: http://www.asrockrack.com/support/ipmi.asp
