C3758D4I-4L / C3558D4I-4L
2 3
English
Management
BMC Controller
ASPEED AST2500 : IPMI (Intelligent Platform Management
Interface) 2.0 with Ikvm and vMedia support
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management LAN
Features
- Watch Dog
- NMI
Gracphics
Controller ASPEED AST2500
VRAM DDR4 64MB
Output Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
Rear Panel I/O
VGA Port 1 x D-sub
USB 3.0 Port 2
LAN Port
- 4 x RJ45 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/UID
LED
1
Serial port 1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion , location button & LED , front
LAN LED, and event log LED)
TPM Header 1
IPMB Header 1
Fan Header 4 pins x4 (1CPU/2Front/1Rear)
ATX Power 1 (24-pin)
DC-IN 1 (8-pin) 12v
SATA POWER 1 (4-pin)
Front Panel 1
USB 2.0 Header 1
System BIOS
BIOS Ty pe 128Mb AMI UEFI Legal BIOS
BIOS Features
- Plug and Play (PnP)
- ACPI 1.1 Compliance Wake Up Events
- SMBIOS 2.3.1 Support
- DRAM Voltage Multi-adjustment
- ASRock Instant Flash
Hardware Monitor
Temperature
- CPU/PCH/DDR/LAN/Storage Temperature Sensing
- MB/Card side/TR1 Temperature Sensing
