ASRock EP2C612D24-4L [14/101] English
![ASRock EP2C612D24-4L [14/101] English](/views2/1694647/page14/bge.png)
8 9
English
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_H3, DDR4_G3, White)*
2 2 x 288-pin DDR4 DIMM Slots (DDR4_H2, DDR4_G2, White)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_H1, DDR4_G1, Blue)
4 ATX 12V Power Connector (ATX12V2)
5 Intelligent Platform Management Bus header (IPMB1)
6 ATX Power Connector (ATXPWR1)
7 ATX 12V Power Connector (ATX12V1)
8 PSU SMBus (PSU_SMB1)
9 Front Fan Connector (FRNT_FAN1)
10 Front Fan Connector (FRNT_FAN2)
11 PMBUS Mode Jumper (PMBUS_SEL_ALT1)
12 PMBUS Mode Jumper (PMBUS_SEL_DAT1)
13 PMBUS Mode Jumper (PMBUS_SEL_CLK1)
14 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)
15 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)
16 2 x 288-pin DDR4 DIMM Slots (DDR4_A3, DDR4_B3, White)
17 CPU 1 Fan Connector (CPU1_FAN1)
18 LGA 2011 R3 CPU Socket 1 (CPU1)
19 2 x 288-pin DDR4 DIMM Slots (DDR4_C3, DDR4_D3, White)
20 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2, White)
21 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)
22 Front Fan Connector (FRNT_FAN4)
23 Front Fan Connector (FRNT_FAN3)
24 Front Fan Connector (FRNT_FAN5)
25 System Panel Header (PANEL1)
26 Auxiliary Panel Header (AUX_PANEL1)
27 SSATA SGPIO Connector (SSATA_SGPIO1)
28 Non Maskable Interrupt Button (NMI_BTN1)
29 SATA SGPIO Connector (SATA_SGPIO2)
30 SATA SGPIO Connector (SATA_SGPIO1)
31 SATA3 Connector (SATA_0)
32 SATA3 Connector (SATA_2)
33 SATA3 Connector (SATA_3)
