EP2C612D24 / EP2C612D24-4L
2 3
English
EP2C612D24-4L:
4 x RJ45 GLAN by Intel® i350AM4
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Quad LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2400
IPMI Dedicated
GLAN
- 1 x Realtek RTL8211E for dedicated management GLAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2400
VRAM DDR3 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
USB 2.0 Port 2
LAN Port EP2C612D24:
2 + 1 (IPMI) LAN port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
EP2C612D24-4L:
4 + 1 (IPMI) LAN port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
Serial Port 1 (COM1)
UID Button/
LED
1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED, and system event LED)
TPM Header 1
IPMB Header 1
Fan Header 2 x CPU Fans, 6 x system Fans (4-pin)
ATX Power 1 (24-pin) + 2 (8-pin)
USB 3.0 Header 1 (supports 2 USB 3.0 ports)
USB 2.0 Header 1 (supports 2 USB 2.0 ports)
Type A USB 3.0
Port
1
