EP2C612D24 / EP2C612D24-4L
8 9
English
No. Description
34 SATA3 Connector (SATA_1)
35 SSATA3 Connector (SSATA_0)**
36 SSATA3 Connector (SSATA_1)
37 SATA3 Connector (SATA_5)
38 SSATA3 Connector (SSATA_3)***
39 SSATA3 Connector (SSATA_2)
40 SATA3 Connector (SATA_4)
41 TPM Header (TPM1)
42 ME Recovery Jumper (ME_RECOVERY1)
43 ermal Sensor Header (TR1)
44 Vertical Type A USB 3.0 (USB3_5)
45 Buzzer (BUZZER1)
46 USB 3.0 Header (USB3_3_4)
47 Speaker Header (SPEAKER1)
48 CPU PECI Mode Jumper (PECI1)
49 Chassis ID3 Jumper (CHASSIS_ID3)
50 BMC SMBus Header (BMC_SMB_3)
51 BMC SMBus Header (BMC_SMB_2)
52 BMC SMBus Header (BMC_SMB_1)
53 Chassis ID2 Jumper (CHASSIS_ID2)
54 Chassis ID1 Jumper (CHASSIS_ID1)
55 USB 2.0 Header (USB_3_4)
56 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_F1, Blue)
57 2 x 288-pin DDR4 DIMM Slots (DDR4_E2, DDR4_F2, White)
58 2 x 288-pin DDR4 DIMM Slots (DDR4_E3, DDR4_F3, White)
59 CPU 2 Fan Connector (CPU2_FAN1)
60 Rear Fan Connector (REAR_FAN1)
61 LGA 2011 R3 CPU Socket 2 (CPU2)
* For DIMM installation and conguration instructions, please see p.24 (Installation of Memory Modules
(DIMM)) for more details.
** e rst “S“ of the “SSATA” means “secondary”. SATA is managed by the rst controller. SSATA is managed
by the secondary controller.
*** SSATA_3 connector is shared with the M2_1.
