2 3
English
1.2 Specications
EP2C612D24 / EP2C612D24-4L
MB Physical Status
Form Factor SSI EEB
Dimension 12'' x 13'' (30.5 cm x 33.0 cm)
Processor System
CPU Intel® Xeon® processor E5-2600 v3/v4* series
*
BIOS version 2.0 or above is required.
Socket Dual Socket LGA 2011 R3
Chipset Intel® C612
System Memory
Capacity 24 DIMM slots
Type - Quad Channel memory technology
- Supports DDR4 2400*/2133/1866/1600 RDIMM and
LRDIMM
*Only E5-2600 V4 CPUs support DDR4 2400.
Voltage 1.2V
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
Expansion Slot
PCIe 3.0 x 8 3 slots
M.2 1 slot (PCIe Gen3 x4 & SATA3)
*SSATA_3 connector is shared with the M2_1.
Storage
SATA
Controller
Intel® C612 : 10 x SATA3 6.0 Gb/s (6 x SATA3 + 4 x SSATA3),
support RAID 0, 1, 5, 10
Ethernet
Interface 1000 /100 /10 Mbps by Intel i350
LAN EP2C612D24:
2 x RJ45 GLAN by Intel® i350AM2
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
