ASRock EP2C612D24-4L [29/101] Installing the cpu fan and heatsink
![ASRock EP2C612D24-4L [29/101] Installing the cpu fan and heatsink](/views2/1694647/page29/bg1d.png)
EP2C612D24 / EP2C612D24-4L
22 23
English
2.4 Installing the CPU Fan and Heatsink
CPU_FAN
1 2
CPU fan for narrow ILM socket
*Support an active or passive heatsink
Before you installed the heatsink, you need to spray thermal interface material between the
CPU and the heatsink to improve heat dissipation.
